AVL Tree

https://www.geeksforgeeks.org/avl-tree-set-1-insertion/

AVL Tree | Set 1 (Insertion) - GeeksforGeeks

https://www.geeksforgeeks.org/avl-tree-set-2-deletion/

AVL Tree | Set 2 (Deletion) - GeeksforGeeks

From geeks for geek

#include <iostream>
using namespace std;
class Node
{
public:
	int key;
	Node* left;
	Node* right;
	int height;
};

// A utility function to get maximum
// of two integers
int max(int a, int b);

// A utility function to get height
// of the tree
int height(Node* N)
{
	if (N == NULL)
		return 0;
	return N->height;
}

// A utility function to get maximum
// of two integers
int max(int a, int b)
{
	return (a > b) ? a : b;
}

/* Helper function that allocates a
new node with the given key and
NULL left and right pointers. */
Node* newNode(int key)
{
	Node* node = new Node();
	node->key = key;
	node->left = NULL;
	node->right = NULL;
	node->height = 1; // new node is initially
					// added at leaf
	return(node);
}

// A utility function to right
// rotate subtree rooted with y
// See the diagram given above.
Node* rightRotate(Node* y)
{
	Node* x = y->left;
	Node* T2 = x->right;

	// Perform rotation
	x->right = y;
	y->left = T2;

	// Update heights
	y->height = max(height(y->left),
		height(y->right)) + 1;
	x->height = max(height(x->left),
		height(x->right)) + 1;

	// Return new root
	return x;
}

// A utility function to left
// rotate subtree rooted with x
// See the diagram given above.
Node* leftRotate(Node* x)
{
	Node* y = x->right;
	Node* T2 = y->left;

	// Perform rotation
	y->left = x;
	x->right = T2;

	// Update heights
	x->height = max(height(x->left),
		height(x->right)) + 1;
	y->height = max(height(y->left),
		height(y->right)) + 1;

	// Return new root
	return y;
}

// Get Balance factor of node N
int getBalance(Node* N)
{
	if (N == NULL)
		return 0;
	return height(N->left) -
		height(N->right);
}

Node* insert(Node* node, int key)
{
	/* 1. Perform the normal BST rotation */
	if (node == NULL)
		return(newNode(key));

	if (key < node->key)
		node->left = insert(node->left, key);
	else if (key > node->key)
		node->right = insert(node->right, key);
	else // Equal keys not allowed
		return node;

	/* 2. Update height of this ancestor node */
	node->height = 1 + max(height(node->left),
		height(node->right));

	/* 3. Get the balance factor of this
		ancestor node to check whether
		this node became unbalanced */
	int balance = getBalance(node);

	// If this node becomes unbalanced,
	// then there are 4 cases

	// Left Left Case
	if (balance > 1 && key < node->left->key)
		return rightRotate(node);

	// Right Right Case
	if (balance < -1 && key > node->right->key)
		return leftRotate(node);

	// Left Right Case
	if (balance > 1 && key > node->left->key)
	{
		node->left = leftRotate(node->left);
		return rightRotate(node);
	}

	// Right Left Case
	if (balance < -1 && key < node->right->key)
	{
		node->right = rightRotate(node->right);
		return leftRotate(node);
	}

	/* return the (unchanged) node pointer */
	return node;
}
Node* deleteNode(Node* root, int key)
{
	// STEP 1: PERFORM STANDARD BST DELETE
	if (root == NULL)
	{
		return root;
	}

	// If the key to be deleted is smaller
	// than the root's key, then it lies
	// in left subtree
	if (key < root->key)
		root->left = deleteNode(root->left, key);

	// If the key to be deleted is greater
	// than the root's key, then it lies
	// in right subtree
	else if (key > root->key)
		root->right = deleteNode(root->right, key);

	// if key is same as root's key, then
	// This is the node to be deleted
	else
	{

		// node with only one child or no child
		if ((root->left == NULL) ||
			(root->right == NULL))
		{
			Node* temp = root->left ?
				root->left :
				root->right;

			// No child case
			if (temp == NULL)
			{
				temp = root;
				root = NULL;
			}
			else // One child case
				*root = *temp; // Copy the contents of
							// the non-empty child
			free(temp);
		}
		else
		{
			// node with two children: Get the inorder
			// successor (smallest in the right subtree)
			Node* temp = minValueNode(root->right);

			// Copy the inorder successor's
			// data to this node
			root->key = temp->key;

			// Delete the inorder successor
			root->right = deleteNode(root->right,
				temp->key);
		}
	}

	// If the tree had only one node
	// then return
	if (root == NULL)
		return root;

	// STEP 2: UPDATE HEIGHT OF THE CURRENT NODE
	root->height = 1 + max(height(root->left),
		height(root->right));

	// STEP 3: GET THE BALANCE FACTOR OF
	// THIS NODE (to check whether this
	// node became unbalanced)
	int balance = getBalance(root);

	// If this node becomes unbalanced,
	// then there are 4 cases

	// Left Left Case
	if (balance > 1 &&
		getBalance(root->left) >= 0)
		return rightRotate(root);

	// Left Right Case
	if (balance > 1 &&
		getBalance(root->left) < 0)
	{
		root->left = leftRotate(root->left);
		return rightRotate(root);
	}

	// Right Right Case
	if (balance < -1 &&
		getBalance(root->right) <= 0)
		return leftRotate(root);

	// Right Left Case
	if (balance < -1 &&
		getBalance(root->right) > 0)
	{
		root->right = rightRotate(root->right);
		return leftRotate(root);
	}

	return root;
}
// A utility function to print preorder
// traversal of the tree.
// The function also prints height
// of every node
void preOrder(Node* root)
{
	if (root != NULL)
	{
		cout << root->key << " ";
		preOrder(root->left);
		preOrder(root->right);
	}
}



My code

Node* findnode(Node* root, int key)
{
	if (root == NULL)
		return root;

	if (key < root->key)
		root->left = findnode(root->left, key);

	else if (key > root->key)
		root->right = findnode(root->right, key);
	else
		return root;
}
Node* minValueNode(Node* node)
{
	Node* current = node;

	while (current->left != NULL)
		current = current->left;

	return current;
}
Node* maxValueNode(Node* node)
{
	Node* current = node;

	while (current->right != NULL)
		current = current->right;

	return current;
}
Node* findbigger(int mScore, Node* node) // finds node that its key value is same or closely bigger than mScore
{

	if (node == NULL)
	{
		return node;
	}
	if (node->key < mScore)
	{
		return findbigger(mScore, node->right);

	}
	else if (node->key > mScore)
	{
		if (node->left == NULL)
			return node;
		Node* maxLeft = maxValueNode(node->left);
		if (maxLeft->key < mScore)
		{
			return node;
		}
		else
		{
			return findbigger(mScore, node->left);
		}
	}
	else
	{
		return node;
	}
}
